02S(consumer) Series Professional Monitor

Products Details

Product Specifications
02S(gaming) Series Professional MonitorDifference contrast
  •
  •   Model U3202S W3202S W3202SH(AUO OC) W3202SH
  •   Panel size 32" 32" 32" 32"
  • Display parameters Backlight category ELED edge Type   ELED edge Type   ELED edge Type   ELED edge Type
  •   Panel UHD VA   FHD IPS   FHD VA   FHD VA
  •   Aspect ratio 16:9   16:9   16:9   16:9
  •   Color Gamut 80%NTSC(95%Optional)   68%NTSC   72%NTSC   72%NTSC
  •   Resolution 3840*2160   1920*1080   1920*1080   1920*1080
  •   Resfresh rate 60Hz   60Hz   144Hz   144Hz
  •   Viewing angle H:178°/V:178°(CR>10)   H:178°/V:178°(CR>10)   H:170°/V:170°(CR>10)   H:178°/V:178°(CR>10)
  •   Brightness 250-300cd/m²   300-350cd/m²   250-300cd/m²   250-300cd/m²
  •   Contrast ratio 1000:1   1400:1   4000:1   3000:1
  •   Response time 9.5ms   8ms   6.5ms   21ms
  •   Response time(With OD) 5.5ms   6.5ms   2.5ms   5ms
  • Specifications Bare dimension 724mm*503mm*183mm   724mm*503mm*183mm   724mm*503mm*183mm   724mm*511*209mm
  •   N.W. 5.5kg   5.5kg   5.5kg   5.5kg
  •   G.W. 8.2kg   7.3kg   7.6kg   8.0kg
  •   VESA Wall Mount 100mm*100mm   100mm*100mm   100mm*100mm   100mm*100mm
  • Input Interface VGA   1
  •   DVI 1   1(-D)   1(-D)   1(-D)
  •   HDMI 2(2.0+1.4)(HDCP1.4)   2(1.4)   1(1.4)   1(1.4)
  •   DP 1(1.2)     1(1.2)   1(1.2)
  •   PC-AUDIO 1   1
  • Output Interface Earphones 1   1   1   1
  • Special Functions Flicker-free Support   Support   Support   Support
  •   Blue-light filtering Support   Support   Support   Support
  •   Touching Nonsupport   Nonsupport   Nonsupport   Nonsupport
  • Accessory LED Monitor 1 PSC   1 PSC   1 PSC   1 PSC
  •   Base 1 PCS(Optional)   1 PCS(Optional)   1 PCS(Optional)   1 PCS(Optional)
  •   Power cord 1 PCS(HDMI Cable)   1 PCS(VGA Cable)   1 PCS(HDMI Cable)   1 PCS(HDMI Cable)
  •   Instructions 1 PCS   1 PCS   1 PCS   1 PCS
  •   Power cable/Adapter 1 PCS   1 PCS   1 PCS   1 PCS
  •
  •   Model Q3202S Q3202SH Q3202SU
  •   Panel size 32" 32" 32"
  • Display parameters Backlight category ELED edge Type   ELED edge Type   ELED edge Type
  •   Panel QHD IPS   UHD VA   UHD VA
  •   Aspect ratio 16:9   16:9   16:9
  •   Color Gamut 72%NTSC(85%Optional)   72%NTSC(85%Optional)   72%NTSC(85%Optional)
  •   Resolution 2560*1440   2560*1440   2560*1440
  •   Resfresh rate 60Hz   60Hz   60Hz
  •   Viewing angle H:178°/V:178°(CR>10)   H:178°/V:178°(CR>10)   H:178°/V:178°(CR>10)
  •   Brightness 250-300cd/m²   200-250cd/m²   250-300cd/m²
  •   Contrast ratio 1200:1   3000:1   1000:1
  •   Response time 8ms   22ms   20ms
  •   Response time(With OD) 6.5ms   5.5ms   6ms
  • Specifications Bare dimension 724mm*503mm*183mm   724mm*503mm*183mm   724mm*503mm*183mm
  •   N.W. TBD   TBD   TBD
  •   G.W. TBD   TBD   TBD
  •   VESA Wall Mount 100mm*100mm   100mm*100mm   100mm*100mm
  • Input Interface VGA 1
  •   DVI   1   1
  •   HDMI 2(1.4)   2(2.0+1.4)(HDCP1.4)   2(2.0+1.4)(HDCP1.4)
  •   DP 2(1.2+Mini1.2)   2(1.2)   2(1.2)
  •   PC-AUDIO   1   1
  • Output Interface Earphones 1   1   1
  • Special Functions Flicker-free Support   Support   Support
  •   Blue-light filtering Support   Support   Support
  •   Touching Nonsupport   Nonsupport   Nonsupport
  • Accessory LED Monitor 1 PSC   1 PSC   1 PSC
  •   Base 1 PCS(Optional)   1 PCS(Optional)   1 PCS(Optional)
  •   Power cord 1 PCS(HDMI Cable)   1 PCS(HDMI Cable)   1 PCS(HDMI Cable)
  •   Instructions 1 PCS   1 PCS   1 PCS
  •   Power cable/Adapter 1 PCS   1 PCS   1 PCS
Remarks: KTC will provide the information as correct as possible. Product photos on this website may vary from the real products. Products information may vary from the products manual available in the market. Please use the products subjected to the specific information on the user manual. For details, please contact the related persons.
